Cup automatic screen printing machine with 8 stations
Model:DX-SPM400
Max printing diameter:¢120mm
Printing color: 1 color or color processing
Cup fixture: 8 stations
Printing speed: about 1500pcs/hr
Machine size: L100*W100*H180cm+L120*W60*H80cm
Power: AC220V/1500W
N.W: 350KGS
Processing:automatic feeding-printing-ink curing-unloading
Optional Devices
1.PLC
2.Servo
3.positioning sensor
4.automatic feeding and unloading
Printing Supplies
1.Screen printing plate
2.screen ink
3.Squeegee（or squeegee with handle）
What’s the Screen Printing?
The basic principle of screen printing is: use the basic principle of the screen printing plate’s graphic part of the mesh to penetrate ink, and the non-graphic part of the mesh to be impermeable to ink. When printing, pour ink into one end of the screen printing plate, apply a certain amount of pressure on the ink part of the screen printing plate with the scraper, and at the same time, print towards the other end of the screen printing plate. The ink is squeezed by the scraper from the mesh of the graphic part to the substrate during the movement.
